Portable DC Arc Welder Cum Generator Model GE-W8000RSi

Portable DC Arc Welder Cum Generator Model GE-W8000RSi

( 2 Reviews )

₹119772 ~~₹135000~~

7906007989

Welding Output Current (Duty Cycle60%) : 300Amps.
Open Circuit Voltage (OCV): 65 Volt
Electrode diameter : 2.6 mm to 4.0 mm
Starting System :Recoil Start / Self Start
Fuel Consumption Ltr/Hr. 60 % Duty Cycle : 2.0 Ltr./hr. (Approx)
Continuous Operating Hour : 13 hr.

Special Highlights & Applications

This is a very Powerful and Portable DC Arc Welder Cum Generator Machine Suitable for All types of General Purpose Structural Welding, Light, & Heavy Welding Jobs, up to 5 mm Electrode
This Welding Generator have in built AC 230 volt – 50 Hz,5 KVA to run AC Appliances like Drill, Cutter, Grinder, Flood lights etc.

This Premium product is Outcome of excellent Hard work of HPM's R&D Engineers. Himalayan Power is more than 25-year company offers Complete Power & Lighting Solutions through > 300 Products & Models. HPM is a 100% Make in India Company with after Sales & Services & spare parts at very economical prices.

Qty:

Product Information

Welding Output Current (Duty Cycle60%): 300 Amps
Welding Output Current (Duty Cycle100%) : 225 Amps.
WorkingVoltage : 20v to35v
OpenCircuit Voltage (OCV) : 65 Volt
Welding CurrentRegulation (Amps) : 50 – 300 AMPS
RectifyingMode : SCR,PhaseControlled3-phase,Rectifying Bridge
MaximumElectrodediameter : 2.6mmto 5.0mm

AC GENERATOR

AC Alternator Type : Brushless , Permanent Magnet Rotor
Maximum Ac Output : 4000VA
Rated Power (VA) : 3500VA
Rated Output Current : 14 Amps.
AC. Output Voltage & Frequency : 230 Volts ± 10 Volts, Single Phase – 50 Hz
Frequency (Adjustable) : 50to60Hz.
Classof Insulation : F

Engine

Model : HM192PY
Type : OHV25°Inclined,Single Cylinder,4 strokes, S.I, Forced Air Cooling
Maximum Power : 16.0 hp @ 3600rpm
Bore x Stroke : 92x67 mm
Displacement : 445 cc
Starting System :Recoil Start / Self Start
Ignition System : TCI(TransistorControl Ignition)
Fuel : Standard Petrol
Fuel Tank Capacity : 25 Liters
Fuel Consumption Ltr/Hr. 60 % Duty Cycle : 2.0 Ltr./hr.
Continuous Operating Hour : 13 hr. Aproxx.
Lube. Oil Capacity : 1200 ml.
Lubricating Oil Consumption : 4.3 gm./Hr.

Standard Accessories

AC Plug : 1Pcs.
Tool Kit : 1 Set
Welder Holder : 1 Nos
Earthing Clamp with 3Mtr. Cable : 1 set
Oil Funnel : 1 Nos.

Panel & Other Standard Features

A.C. Circuit Protector (NFB) : Yes
Volt-Hz-Hour Meter : Yes, Multifunction Digital Meter Provided
DC Welding Amps. Meter : Yes
A.C. Overload/ Fault Indicator : Yes
Low Engine Oil Indicator : Yes
Fuel Level Gauge : Yes
A.C. Output Sockets : Yes
Costar Wheels and handles : Yes
Mono Rail Wheels : Yes

Size & Weight

Dimension LxWxH (mm) : 670 x 510 x 670 mm
Dry Weight (Kgs.): 103 KG

Above Specifications are for reference only, Because of continuous improvements and up-gradation by our R&D team. This specification’s can change without any prior intimation
